cpu

   S5N8947 (72MHz)

   RTOS BOOT ROM

   128Kbyte EEPROM

   SDRAM

   16Mbyte System Memory

   Flash ROM3

   8Mbyte application  F/W Memory

   LAN Controller

   STE 100P

   Card Reade

   8 Reader 지원

   Sensor Input

   16 Port

   Relay Output

   8 Port

   Upgrade

   TFTP 방식으로 쉬운 Upgrade

   Output interface

   TCP/IP

   Event buffer

   10만 건

   ID Master

   10만 매

   LCD

   20 x 4 Line

   Operating temperature

   -30℃ ~ 80℃

   Power supply input

   입력 AC110V/220V, 출력 DC5V/1.2A

   Back-up Battery

   12V, 12AH( 2-3시간 대기)

   Dimensions

   400W x 500H x 150D(mm)
